Programmable 80L Climatic Test Chamber With LCD Touch Screen

Product Categories

ASLi (CHINA) TEST EQUIPMENT CO., LTD

Contact Now

Programmable 80L Climatic Test Chamber With LCD Touch Screen

Ask Lasest Price
Brand Name :	ASLI
Model Number :	TH-80-E
Certification :	CE
Price :	negotiable
Payment Terms :	T/T, L/C, Western Union
Supply Ability :	50 sets per month
Delivery Time :	15~20days

Add to Cart

Product Details
Company Profile

Programmable 80L Climatic Test Chamber With LCD Touch Screen

Temperature Humidity Test Machine th-225-e.pdf

Temperature And Humidity Climatic Test Chamber Price, Temperature And Humidity Control System

CHAMBER DESIGN FEATURES
1. High performance and quiet operation (68 dBA)
2. Space-saving designed for flush installation to wall
3. Full thermal break around doorframe
4. One 50mm diameter cable port o left, with flexible silicone plug
5. Accurate wet/dry-bulb humidity measurement system for easy
maintain

PROGRAMMABLE CONTROLLER
1. PLC controller for test chamber
2. Step types include: ramp, soak, jump, auto-start, and end
3. RS-232 interface to connect computer for output
Name
Temperature Humidity Climate Testing Chamber
Model
TH-80(A~F)
TH-150(A~F)
TH-225(A~F)
Internal Dimension WxHxD (mm)
400x500x400
500x600x500
600x750x500
External Dimension WxHxD (mm)
950x1650x950
1050x1750x1050
1200x1900x1150
Temperature Range
Low Temperature(A:25℃ B:0℃ C:-20℃ D:-40℃ E:-60℃ F:-70℃)High Temperature 150℃
Humidity Range
20%~98%R.H.(10%-98% R.H. / 5%-98% R.H ,is optional , need
Dehumidifier)
Control Accuracy of Temperature and Humidity
±0.5℃; ±2.5% R.H.
Temperature Rising/Falling Velocity
Temperature rising approx. 0.1~3.0℃/min ;temperature falling approx. 0.1~1.0℃/min;
( Falling Min.1.5℃/min is optional)
Optional Accessories
Inner door with operation hole , Recorder, Water Purifier,
Dehumidifier
Weight (kg)
150
180
250

APPLICATIONS
1. Humidity Temperature Testing Chamber to simulate test environment with different temperature and humidity
2. Cyclic test includes climatic conditions: holding test, cooling-off test, heating-up test, moistening test and drying test...
3. Cable port with flexible silicone plug for cable routing to provide the condition of test unit under operation
4. Uncover test unit weakness in a short-term test with accelerated time effect

Humidity Temperature Testing Chamber Specifications

1.Imported LCD display screen, capable of displaying the measured
value as well as the set value and time.
2.Fixed condition or programmable condition can be set.
3.Fixed condition setting time range: 0 - 99999 H 59 MIN .
4.Programmable mold can set 269 different program at the same time,
each program can set several segment to do cycle testing
5.Each program can have max.50 segment with different temperature
setting,segment running time Max.530 hr 59 min, Max.can do 13450
times cycle.
6.With power off memory device, reply message to continue with the
rest of the program.
7.The control unit has slope control of temperature, and with Self
calibration temperature function
8.With TIMER SIGNAL OUTPUT RELAY.
9.Temperature sensor adopt DIN PT-100Ω
